CCNP Enterprise ENARSI 300-410 Study Guide

Complete CCNP Enterprise ENARSI 300-410 study guide covering advanced EIGRP, OSPF, BGP, DMVPN, route redistribution, QoS, and infrastructure security.

·Published March 29, 2026 ·Editorial standards
7 min read·734 views
CCNP Enterprise ENARSI 300-410 Study Guide

What does the ENARSI 300-410 exam cover?

The CCNP Enterprise ENARSI (300-410) concentration exam covers advanced routing and services topics including EIGRP, OSPF, BGP, route redistribution, path control, VPN technologies, infrastructure security, and services. It is one of the concentration options for completing the CCNP Enterprise certification after passing the ENCOR core exam. The exam costs $300 USD and is 90 minutes long.

The Cisco CCNP Enterprise ENARSI 300-410 (Implementing Cisco Enterprise Advanced Routing and Services) is the routing and switching concentration exam for the CCNP Enterprise certification. It goes deep into the routing protocols and network services that senior network engineers manage daily in enterprise environments, focusing on advanced configuration, optimization, and troubleshooting.

ENARSI is the most popular CCNP Enterprise concentration because routing is a foundational skill for enterprise network engineers. Engineers who complete ENCOR + ENARSI demonstrate comprehensive enterprise networking expertise. The exam costs $300 USD and is 90 minutes long.

Exam Overview

Detail Information
Exam Code 300-410 ENARSI
Full Name Implementing Cisco Enterprise Advanced Routing and Services
Number of Questions 55-65
Time Limit 90 minutes
Passing Score ~825/1000
Cost $300 USD
Prerequisites ENCOR 350-401 core exam must be passed
Certification Completes CCNP Enterprise with ENCOR
Validity 3 years

The exam covers four domains:

  1. Layer 3 technologies (40%)
  2. VPN technologies (20%)
  3. Infrastructure security (20%)
  4. Infrastructure services (20%)

"ENARSI is a specialist exam. Every question is about advanced routing. The candidate who has built and troubleshot EIGRP, OSPF, and BGP in real environments will find the questions familiar. The candidate who has only studied from books will find that the configuration and troubleshooting scenarios expose gaps that reading alone cannot fill." -- CCNP routing specialist community

Domain 1: Layer 3 Technologies (40%)

EIGRP Advanced Operations

EIGRP Named Mode is the modern configuration style:

router eigrp ENTERPRISE
  address-family ipv4 unicast autonomous-system 100
    network 10.0.0.0 0.255.255.255
    eigrp stub connected summary
    af-interface GigabitEthernet0/0
      authentication mode md5
      authentication key-chain EIGRP-KEYS
    topology base
      redistribute ospf 1 metric 10000 100 255 1 1500

EIGRP route filtering with distribute lists and prefix lists controls which routes are advertised or accepted:

  • Distribute lists reference ACLs or prefix lists
  • Route maps provide more granular matching and modification
  • Offset lists adjust EIGRP metric for specific routes

OSPF Advanced Operations

OSPF virtual links connect areas that cannot physically connect to Area 0, using another area as a transit. The virtual link command specifies the remote ABR's router ID and the transit area.

OSPF route filtering:

  • distribute-list with ACL or prefix-list: Filters routes from being installed in the routing table (does not prevent LSA propagation)
  • Type 3 LSA filtering at ABRs: Filters summary LSAs from being sent into areas
  • Type 5/Type 7 filtering at ASBRs: Filters external routes

OSPF path manipulation:

  • Interface cost modification
  • Reference bandwidth adjustment (auto-cost reference-bandwidth)
  • Summarization at ABRs (area X range) and ASBRs (summary-address)

BGP Advanced Configuration

BGP route reflectors solve the IBGP full-mesh requirement:

  • Route reflectors re-advertise IBGP-learned routes to other IBGP peers (clients and non-clients)
  • Cluster-ID: Prevents routing loops in route reflector clusters
  • Originator-ID: Prevents loops by marking the originating router

BGP route filtering and path manipulation:

Tool What It Does Scope
Prefix list Match specific prefixes with ge/le operators Most efficient prefix filtering
AS-path ACL Filter based on AS-path regular expressions Filter by origin or transit AS
Route map Multi-attribute matching and modification Most flexible; can set and match multiple attributes
Community strings Tagging routes for downstream policy Scalable policy propagation

BGP communities:

  • Standard communities: 32-bit value (AS:value format, e.g., 65001:200)
  • Well-known communities: NO_EXPORT, NO_ADVERTISE, LOCAL_AS
  • Extended communities: Used for MPLS VPN route targets

Route Redistribution

Route redistribution connects different routing domains:

router ospf 1
  redistribute eigrp 100 subnets route-map EIGRP-TO-OSPF

route-map EIGRP-TO-OSPF permit 10
  match ip address prefix-list EIGRP-PREFIXES
  set metric 100
  set metric-type type-1

Redistribution challenges:

  • Suboptimal routing: Routes may take longer paths due to metric differences
  • Routing loops: Bidirectional redistribution without proper filtering can cause routing loops
  • Route tagging: Using route tags to identify redistributed routes and prevent re-redistribution

Domain 2: VPN Technologies (20%)

DMVPN (Dynamic Multipoint VPN)

DMVPN provides scalable site-to-site VPN with dynamic spoke-to-spoke tunnels:

  • mGRE (multipoint GRE): Hub uses a single tunnel interface for all spoke connections
  • NHRP (Next Hop Resolution Protocol): Protocol that enables spokes to discover each other's real IP addresses
  • Phase 1: All traffic routes through hub
  • Phase 2: Spokes can build direct tunnels after initial hub traversal
  • Phase 3: Hierarchical DMVPN with summarization at hub for maximum scalability

IPsec Integration

DMVPN uses IPsec for encryption. The exam tests:

  • IKEv2 vs. IKEv1 differences
  • IPsec transform sets and profiles
  • Crypto map vs. tunnel protection (tunnel protection is the modern approach for DMVPN)

Domain 3: Infrastructure Security (20%)

Control Plane Security

Control Plane Policing (CoPP) protects the router CPU from DoS attacks targeting management protocols:

class-map match-any CRITICAL
  match access-group name BGP-PEERS

policy-map COPP-POLICY
  class CRITICAL
    police rate 64000 bps
  class class-default
    police rate 8000 bps

control-plane
  service-policy input COPP-POLICY

uRPF (Unicast Reverse Path Forwarding) prevents IP spoofing:

  • Strict mode: Source IP must be reachable via the interface it arrived on
  • Loose mode: Source IP must exist in the routing table (any interface)

Management Plane Security

  • SSH: Encrypted remote management (replace Telnet)
  • SNMP v3: Authenticated and encrypted SNMP (replace v1/v2c)
  • AAA with TACACS+: Centralized authentication, authorization, and accounting for device management
  • Management VRF: Isolating management traffic in a dedicated VRF

Domain 4: Infrastructure Services (20%)

Network Address Translation

NAT Type Description Use Case
Static NAT One-to-one permanent mapping Server requiring fixed public IP
Dynamic NAT Pool of public IPs assigned dynamically Multiple internal hosts needing internet
PAT/NAT Overload Many-to-one using port numbers Most enterprise internet connections
NAT64 IPv6-to-IPv4 translation Transitioning environments

Quality of Service

Modular QoS CLI (MQC) is the Cisco standard for QoS configuration:

  1. Class maps: Define traffic classes using match criteria
  2. Policy maps: Define actions for each class
  3. Service policies: Apply policy maps to interfaces (in or out direction)

CBWFQ (Class-Based Weighted Fair Queuing) provides minimum bandwidth guarantees per class. LLQ (Low Latency Queuing) adds a strict priority queue for voice traffic.

First Hop Redundancy Protocols

HSRP (Hot Standby Router Protocol):

  • Cisco-proprietary
  • Virtual IP and virtual MAC
  • Active router handles traffic; standby router monitors
  • Preemption configuration determines whether a router takes active role when it recovers

VRRP (Virtual Router Redundancy Protocol):

  • Industry-standard (RFC 5798)
  • The router with the virtual IP as its real IP automatically becomes master
  • Similar functionality to HSRP

GLBP (Gateway Load Balancing Protocol):

  • Cisco-proprietary
  • Unique: all routers can forward traffic simultaneously
  • AVG (Active Virtual Gateway) assigns different virtual MACs to each AVF (Active Virtual Forwarder)
  • Provides both redundancy and load balancing

Frequently Asked Questions

How does ENARSI differ from ENCOR for routing topics? ENCOR covers routing protocols at an advanced conceptual level, testing design decisions and troubleshooting methodology. ENARSI goes deeper into the specific configurations, filtering mechanisms, and protocol details. ENCOR tests the "what and why" of routing; ENARSI tests the "exactly how to configure and troubleshoot." Both require hands-on lab practice, but ENARSI demands even more time with specific commands and protocol behaviors.

What is the best lab topology for ENARSI preparation? A topology with at least four routers running EIGRP, OSPF, and BGP in different areas, connected through redistribution points, provides the most coverage. Adding a DMVPN hub-and-spoke overlay, route filtering scenarios, and infrastructure security configurations creates a comprehensive practice environment. Cisco Modeling Labs (CML) or EVE-NG with Cisco IOS-XE images are recommended platforms for building this topology.

Can ENARSI be used toward CCIE? Passing the CCNP Enterprise ENCOR core exam (350-401) satisfies the written exam requirement for CCIE Enterprise Infrastructure. Passing ENARSI is not a requirement for CCIE but represents complementary study that strengthens the routing knowledge tested in the CCIE lab exam. Many CCIE candidates pursue CCNP Enterprise (ENCOR + ENARSI) as part of their CCIE preparation path.

References

  1. Cisco. (2025). 300-410 ENARSI Exam Topics. https://learningnetwork.cisco.com/s/enarsi-exam-topics
  2. Teare, D., Vachon, B., & Graziani, R. (2023). CCNP Enterprise Advanced Routing ENARSI 300-410 Official Cert Guide. Cisco Press.
  3. Doyle, J., & Carroll, J. (2022). Routing TCP/IP, Volume 1 (3rd ed.). Cisco Press.
  4. Cisco. (2025). DMVPN Configuration Guide. https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/sec_conn_dmvpn/
  5. Cisco. (2025). BGP Best Practices. https://www.cisco.com/c/en/us/support/docs/ip/border-gateway-protocol-bgp/
  6. Cisco. (2025). Control Plane Policing Configuration Guide. https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/qos_plcshp/configuration/
